Old 12-15-2006, 04:15 AM   #1
kyote
Board Member

kyote's Avatar

Join Date: Apr 2003
Location: La Porte TX
Default 240 Coilovers: The Kyote Way

A Coilover suspension with decent dampers is an excellent addition to any Volvo 240. This guide will teach you to put together a serious suspension on a shoestring budget, in the true spirit of TurboBricks.

-Estimated cost:
~$300 without a strut upgrade (the ultra-broke ass budget option), add $240 for Boge Turbo Gas (the ghetto alternative, from fcpgroton.com), add $379 for Bilsteins from shox.com (A better approach), add $537.60 for Konis from shox.com (RMO (Rich Man's Option)). If your vehicle doesn't already have upgraded swaybars, it would be a good idea to upgrade them while it is apart, using either IPD Safety Swaybars or Dual Sways if you're on the Turbobricks budget (http://forums.turbobricks.com/showthread.php?t=9587).

-Materials:
2x 7" Coil Over Kit (2.08" ID) http://www.colemanracing.com/catalog...oducts_id=1528
2x 2.5"x10" Coil Springs in the rate of your choice (in my case 275lb Suspension Spring Specialists springs)
http://www.colemanracing.com/catalog...oducts_id=4097
2x 5"x11" Coil Springs in the rate of your choice (in my case 250lb Hypercoils springs)
http://www.colemanracing.com/catalog...oducts_id=6207
4x Shocks/Struts of your choice (in my case Bilstein HD's from shox.com)
2x Volvo 240 Upper Rear Spring perches ($4 each from the local Pick-n-Pull, save the bolts)

-It should be noted that a little welding and grinding and drilling may be required; If you were a VolvoSpeeder you might pay someone to do the work necessary for this project, but that is not the turbobricks way. The only tool necessary other than Sockets and Spanners is an angle grinder (a $20 Harbor freight unit will suffice), and a welder (a local welder/exhaust shop is a cheaper approach).

-We begin by removing the strut assembly from the vehicle.



-Remove the brake caliper and disk, the coil spring and strut mount (you can borrow a spring compressor from the local autozone or torch the spring until it relaxes), and the strut insert. At this point you should have this in front of you:



-Using your angle grinder, carefully grind out the welds on the factory spring perches, apply BFH if necessary, leaving you with this:



-At this point you can either have the strut tubes milled down a few hundreths (RMO), or use your Angle grinder to shave the strut tube down enough to allow the threaded sleeves to fit over them (The TurboBricks way, and my choice; However, this job used up almost a whole brand new grinding wheel.). Leaving you with this:



-Now you can either weld on stop rings or have a shop do it for you (I had my little brother do it in his Welding class).



-Next, drill out the holes in the upper spring seat to fit the slightly larger volvo strut.

-Reassemble strut as shown:
(more, better photos coming soon)


-Reinstall front strut assemblies.
(photos coming soon)

-Moving on to the rear, jack up the car using jackstands on the jacking points, remove wheels, and then lift from the pumpkin again until the tension comes off of the lower shock bolt, then remove it. Release jack and allow rear suspension to droop. Unbolt stock springs, keep the nuts. Now, remember those bolts that you saved at the junkyard? Using them and the nuts you just removed, bolt the stock 240 upper spring perches where the spring retainers were previously located. Insert your new shiny springs, lift up rear end and replace lower shock bolts, reinstall wheels, take the car off the stands and thats that.
Upper Spring Seat

Lower Spring Seat


Well, that should be a pretty good guide to coilover suspension on a budget, and I will be adding more photos soon. If you have any edits/suggestions, just post that schizzz below
-<3 kyote
__________________
-78 242 tic, a kyotefab/willettrun joint
-84 244 Baja Edition
-91 244 Daily, Air Conditioned
-98 Lumina Dirt Track Race Car
-90 F350 7.3 IDI Flatbed

Last edited by kyote; 12-17-2006 at 04:40 PM..
kyote is offline   Reply With Quote
Old 12-15-2006, 01:02 PM   #2
towerymt
the real Towery

towerymt's Avatar

Join Date: Sep 2002
Location: VA, USA
Default

In the turbobricks way, you should have put a cut off wheel on your angle grinder and carefully cut through the tabs on the strut that support the brake lines. Bend tab out of the way to release the brake line and hang the caliper. No need to open the brake lines that way. Reinstall is reverse of removal.

You could also knock the welder out of the list of requirements by leaving a little bit of the stock spring perch for the lower stop. Just buy 5" sleeves. This also guarantees that you don't have any wheel/tire fit issue up front since you wouldn't be adding anything below the stock seat. Mount longer sleeves lower, and you've slightly reduced space to the inside where the tire may rub the strut tube (rare situations, but I've rubbed the stock strut tube before my coilovers when I used really wide tires).

15x7 ET12 MSW wheels with a normal 225 width street tire or narrower should clear the spring seat if you did lower it all the way down next to the tire. My 225/50 Bridgestones JUST touch the spring seat, but they're extremely wide for a 225. 205/55 is a safe bet on those wheels. With a 205 on a Virgo, I can't run the spring seat next to the tire. But I also can't drive the car when mine is adjusted that low, so it doesn't matter. You'd probably need 14" springs to put the lower mount that far down anyway.

Otherwise, looks good. I used a belt sander for the "precision strut tube adjustment", but I'm sure the grinder works well too. A 24grit flap wheel on my angle grinder (<$20 @Harbor Freight) works great on metal too and maybe it would be easier to control than the grinder wheel. Install the fronts yet?
__________________
1987 244 | Project Thread | The 87 | Now with 74 mods and counting
1992 244 | The 92
Quote:
Originally Posted by Poik View Post
244s are drop dead ugly and suck.
towerymt is offline   Reply With Quote
Old 12-16-2006, 05:15 PM   #3
coldfusion21
NA is so slow...

Join Date: Jun 2003
Location: Oregon, SW Portland-somewhere
Default

go with the flap wheel, i used a 36 grit, that will let you take the extra seat material away and take off the paint (which is mostly all thats needed)
__________________
novolvo.
coldfusion21 is offline   Reply With Quote
Old 07-15-2007, 02:05 AM   #4
VolvoPunch
Board Member

VolvoPunch's Avatar

Join Date: Sep 2006
Location: Atlanta
Default

I need to try this out. It's the only way i could afford coil overs on my car. Anyways how do to like them? Are the holding up well? Can you post more pictures?
VolvoPunch is offline   Reply With Quote
Old 07-15-2007, 03:18 AM   #5
VQ
Not such a PRVert Anymore

VQ's Avatar

Join Date: Oct 2005
Location: Melbourne, Australia
Default

Makes me want to keep my 264 just for experimental suspension work....
__________________

hellastock
Speed Bumps? No Problem.


264 GLE RIP
88 740T wagon
1964 122s

88 760GLE
VQ is offline   Reply With Quote
Old 07-16-2007, 01:22 AM   #6
kyote
Board Member

kyote's Avatar

Join Date: Apr 2003
Location: La Porte TX
Default

Quote:
Originally Posted by VolvoPunch View Post
I need to try this out. It's the only way i could afford coil overs on my car. Anyways how do to like them? Are the holding up well? Can you post more pictures?
I love them. Bouncy roads suck ass though. Holding up like a champ!
kyote is offline   Reply With Quote
Old 08-15-2007, 01:15 AM   #7
GreatDaneShane
Board Member

GreatDaneShane's Avatar

Join Date: Jul 2007
Location: San Marcos, Texas
Default

hey, i welded those!
GreatDaneShane is offline   Reply With Quote
Old 08-15-2007, 01:48 AM   #8
kyote
Board Member

kyote's Avatar

Join Date: Apr 2003
Location: La Porte TX
Default

hay...
kyote is offline   Reply With Quote
Old 08-15-2007, 08:38 AM   #9
SteveMD
Membro

SteveMD's Avatar

Join Date: Feb 2004
Location: West of I-270
Default

I used evil genius (Ground Control) sleeves, etc. They are a loose fit over the strut tube, about 2mm loosey so I returned to Home Depot for some of those metal plates used in deck framing, bent them roundy to fit the tube and got a nice tight fit with the sleeves. I also filled the strut tube with ATF per the instructions from evil genius for heat transfer from the Koni. One PITA with doing that is you have to make sure the ball joint seals good against the bottom of the strut tube. My left one has a slow ATF leak

I paid a shop $40 to weld on stop rings. The guy knew what he was doing, did it nice, slow, and staggered to avoid the tube tweaking out of straight from the heat.

+1 on Towery's suggestion to slot the brake line tabs on the struts so you don't have to disconnec the lines. I did that.
SteveMD is offline   Reply With Quote
Old 08-15-2007, 10:27 PM   #10
Josepilove
Board Member

Join Date: Mar 2006
Location: Grafton, WI
Default

what kind of height does this allow for? highest? lowest? what height is the rear at with those springs? can i see a picture of how the car sits? thanks, i am really considering this!
Josepilove is offline   Reply With Quote
Old 11-20-2007, 10:25 AM   #11
740ATL
Guest

Default

any updates? How does the car feel?
  Reply With Quote
Old 11-20-2007, 10:26 AM   #12
benflynn
bigpimpin740t@yahoo.com

benflynn's Avatar

Join Date: Mar 2005
Location: Birmingham Al
Default

same thing for 700?
__________________
think you got shorted? belive me, we have piles of turbos and ms units, email me w/what ever the hell you think we have of yours and when i am not on a river ill dig it out and send it to ya for shipping, one shotbigpimpin740t@yahoo.com

one down, whose next?
benflynn is offline   Reply With Quote
Old 11-20-2007, 10:54 AM   #13
blkaplan
50 shades of beige

blkaplan's Avatar

Join Date: Jul 2002
Location: Rockville, MD
Default

I have listed the coilover components we use for sale individually on my website for those who want to to piece together their own components

http://www.kaplhenke.com/collections...mponents-parts





__________________
www.BEIGEPOWER.com
Kaplhenke Racing Facebook
Quote:
Originally Posted by DarkKratoz View Post
The only safe bet is Ben.©

Last edited by blkaplan; 07-15-2014 at 10:01 AM..
blkaplan is offline   Reply With Quote
Old 11-20-2007, 01:17 PM   #14
towerymt
the real Towery

towerymt's Avatar

Join Date: Sep 2002
Location: VA, USA
Default

Quote:
Originally Posted by MrSteve View Post
I also filled the strut tube with ATF per the instructions from evil genius for heat transfer from the Koni. One PITA with doing that is you have to make sure the ball joint seals good against the bottom of the strut tube. My left one has a slow ATF leak
When my Bilstein HD struts started to leak fluid, I noticed it because the ball joint holder was wet. I don't think I'd have dumped fluid in there on purpose because of that.

Quote:
I paid a shop $40 to weld on stop rings. The guy knew what he was doing, did it nice, slow, and staggered to avoid the tube tweaking out of straight from the heat.
Right on par with the $30 I paid for slow welding. He cooled the weld with a wet rag. But it's really more effort than it's worth. I don't think it needs a full bead all the way around. When I replaced a tube, Rob and I did the swap and I had him tack a few welds onto the tube to hold the collar and it's been fine.
towerymt is offline   Reply With Quote
Old 11-20-2007, 02:15 PM   #15
blkaplan
50 shades of beige

blkaplan's Avatar

Join Date: Jul 2002
Location: Rockville, MD
Default

Quote:
Originally Posted by towerymt View Post
When my Bilstein HD struts started to leak fluid, I noticed it because the ball joint holder was wet. I don't think I'd have dumped fluid in there on purpose because of that.
It wouldn't make sense to fill a strut tube using a bilstein with ATF.
blkaplan is offline   Reply With Quote
Old 11-20-2007, 02:56 PM   #16
Mueller
Board Member

Mueller's Avatar

Join Date: Oct 2004
Location: Antioch, CA
Default

Quote:
Originally Posted by Josepilove View Post
what kind of height does this allow for? highest? lowest? what height is the rear at with those springs? can i see a picture of how the car sits? thanks, i am really considering this!
it really depends on the insert used and it's travel (as well as picking the correct spring length)

for super low, a shorter insert allows you to get more travel without worring about bottoming out the insert...for my car, I am using Koni inserts which are 3" shorter, so I cut my struts 3"...this is not really needed for most applications and is slightly overkill for me as well


__________________
Steel gantry for sale or trade

Jack, I think you really need this and you have the parts I need....
Mueller is offline   Reply With Quote
Old 11-21-2007, 04:56 AM   #17
rclark
Board Member

Join Date: Dec 2006
Location: Eugene
Default

probably a stupid question, but i want to make sure i'm going to buy the right thing if/when i do this: it says in the bottom section of the sleeve part to specify the type of shock:
"NOTE: Specify type of shock (above kits with perm, mold tops)"

Do I want the permanent molded tops or w/e they are saying? is the link to the sleeves the exact ones you used?
__________________
"You won't be laughing when your blowup doll has a headache and won't give up that ass."
-Aesop Rock
rclark is offline   Reply With Quote
Old 11-21-2007, 09:48 AM   #18
SteveMD
Membro

SteveMD's Avatar

Join Date: Feb 2004
Location: West of I-270
Default

Quote:
Originally Posted by towerymt View Post
When my Bilstein HD struts started to leak fluid, I noticed it because the ball joint holder was wet. I don't think I'd have dumped fluid in there on purpose because of that.
I'm using Koni's but your point still applies. Who knows what color the shock fluid is. Hopefully not red like atf.
SteveMD is offline   Reply With Quote
Old 11-21-2007, 11:54 AM   #19
towerymt
the real Towery

towerymt's Avatar

Join Date: Sep 2002
Location: VA, USA
Default

My only point was that fluid leaked out of both of mine, so I would not expect ATF or shock oil to be held back.
towerymt is offline   Reply With Quote
Old 11-21-2007, 11:57 AM   #20
blkaplan
50 shades of beige

blkaplan's Avatar

Join Date: Jul 2002
Location: Rockville, MD
Default

Quote:
Originally Posted by towerymt View Post
My only point was that fluid leaked out of both of mine, so I would not expect ATF or shock oil to be held back.
if you are planning to add a fluid, i would think you might add some RTV or some other sealant to prevent embarrassing leakage.
blkaplan is offline   Reply With Quote
Old 11-21-2007, 01:14 PM   #21
qwkswede
faster than you think

Join Date: Mar 2003
Location: Denver, CO
Default

This article might be better with an adjustable height rear setup. Any tips on doing that? Then you can really balance the height and corner weights on the car.
__________________
-Ken
1967 Volvo 122S
1992 Volvo 244 driver
qwkswede is offline   Reply With Quote
Old 11-21-2007, 01:48 PM   #22
m4ff3w
Board Member

m4ff3w's Avatar

Join Date: Jul 2006
Location: ♂ SA, TX ♂
Default

Quote:
Originally Posted by blkaplan View Post
this approach really only works with the 700 series if you get a camber plate style upper mount.

thats not a bad thing though.
That is exactly what I did.

And I love the Camber plates as well.

I have 300#/in springs up front and 275#/in in the rear, IPD 25mm bar up front and no bar on the rear.

I likey very much.
__________________
1984 Maserati Biturbo (2.8l EFI swap in progress)
1977 Fiat X1/9 (daily)
1989 Mercedes 190E 2.6 (wife's)
m4ff3w is offline   Reply With Quote
Old 11-21-2007, 02:06 PM   #23
SteveMD
Membro

SteveMD's Avatar

Join Date: Feb 2004
Location: West of I-270
Default

Quote:
Originally Posted by blkaplan View Post
if you are planning to add a fluid, i would think you might add some RTV or some other sealant to prevent embarrassing leakage.
I did clean/deburr the mating surfaces of the strut bottoms and the BJ's and used supposedly oil resistant RTV on both. Only the left decided to leak.
SteveMD is offline   Reply With Quote
Old 03-14-2008, 09:56 PM   #24
lunar240z
Board Member

lunar240z's Avatar

Join Date: Jul 2007
Location: San Leandro, CA
Default

Quote:
Originally Posted by blkaplan View Post
this approach really only works with the 700 series if you get a camber plate style upper mount.

thats not a bad thing though.
Why is that? The upper spring seat not fitting with the new spring well?

For diy coilovers for s30 Zcars, [which i have done on mine 240z, but used camber plates.] people weld in a 2.5" ring into the top hat, to center the spring. think that would work? i haven't looked in there to extensively yet.
__________________
Sim

1991 745 TIC 15g@13psi, 3" exhaust, 3" intake, ebay intercooler, cfi injectors, 960maf, e-fan, diy strut bars, ipd sways, Plaid



2008 STi Hatch DD

1971 240 Z w/SR20ve+t, s15 6speed,vlsd,GT2871R, Tial44, diy manifolds, Vmount IC, 3" exhaust, 16" watanabes,diy coilovers, wilwood 4pistons all around project car

Last edited by lunar240z; 03-15-2008 at 02:46 AM..
lunar240z is offline   Reply With Quote
Old 03-15-2008, 02:15 AM   #25
Jordan
Board Member

Jordan's Avatar

Join Date: Jul 2005
Location: Tacoma, WA
Default

Quote:
Originally Posted by Mueller View Post
it really depends on the insert used and it's travel (as well as picking the correct spring length)

for super low, a shorter insert allows you to get more travel without worring about bottoming out the insert...for my car, I am using Koni inserts which are 3" shorter, so I cut my struts 3"...this is not really needed for most applications and is slightly overkill for me as well


Where did you pick up those Koni's?
__________________
My Buyer/Seller Feedback Thread
Jordan is offline   Reply With Quote
Reply

Thread Tools
Display Modes

Posting Rules
You may not post new threads
You may not post replies
You may not post attachments
You may not edit your posts

BB code is On
Smilies are On
[IMG] code is On
HTML code is On

Forum Jump


All times are GMT -4. The time now is 10:08 PM.

Powered by vBulletin® Version 3.8.9
Copyright ©2000 - 2017, vBulletin Solutions, Inc.
